Lake People DIGI-TOOL F611
Produktinformationen "Lake People DIGI-TOOL F611"
| 2 x 1 in 4 AES/EBU SPLITTER F611 |
| - 2 modules with each 1 input and 4 outputs - Inputs and outputs transformer balanced, impedance 110 ohms via XLR sockets according to AES 3/11 - High sensitive inputs to regenerate unproper or weak input signals - High output voltages to drive long distances The SYNC UNIT option offers the following features: - 3 external inputs AES/EBU, AES-id, WCLK - 1 AES-EBU sync output - Internal oscillators with 32, 44.1, 48, 88.2, 96, 176.4, 196 kHz - Failsafe operation through switchable Auto-Mode Multimode power supply 90 … 260V AC - 19”, 1 U stainless steel case, front dark grey |
Specifications:
| Inputs: | 2 x XLR female, transformer balanced | |
| according to AES 3/11 | ||
| Input impedance: | 110 ohms | |
| Input sensitivity: | < 200 mV | |
| Outputs: | 2 x 4 XLR male, transformer balanced | |
| according to AES 3/11 | ||
| Output impedance: | 110 ohms | |
| Output level: | > 4V | |
| Output rise time: | limited to 10 nSec | |
| Output jitter: | < 1 nS | |
| Power supply: | 90 … 260 V AC, 12 VA | |
| Dimensions: | 483x44x166 mm (WxHxD), 19", 1U | |
| Case: | Stainless steel | |
| Finish: | Front dark grey | |
| OPTION: | SYNC UNIT |
